THE ANELLO IMU+
TECHNICAL SPECIFICATIONS
ANELLO IMU+
TECHNICAL SPECIFICATIONS
| Gyroscope Performance | MEMS | Z-Axis - Optical Gyro |
|---|---|---|
| Range | up to 400°/s | +/- 200º/s |
| Angle Random Walk | 0.3°/√hr | 0.05°/√hr |
| Bias Instability | 1.5°/hr | 0.5°/hr |
| Scale Factor Error | < 0.1% FS | < 0.1% (0 – 200°/s) |
Accelerometer Performance
| Range | 8g | |
| Velocity Random Walk | 0.03m/s/√hr | |
| Bias Instability | 20μg | |
| Bias over Temp | 5mg |
Environmental
| Operating Temperature1 | -40 to +70°C | |
| Vibration | 5g rms | |
| Shock Survival | 40g |
Electrical
| Input Voltage | 8 to 30 VDC | |
| Power Consumption | 2.5W typical | |
| Digital Interfaces | RS-232 (2 Ports) |
Timing
| Output Data Rate | 200 Hz (Configurable) | |
| Synchronization | PPS In | |
| Bandwidth | up to 100 Hz |
Physical
| Size | 75 x 75 x 28mm (9.8in3) | |
| Weight | < 1lbs. |
